Activated carbon can remove many dissolved heavy metals from water and some heavy metals from gases, especially when the activated carbon is chemically modified or impregnated for specific metal ions. However, the efficiency of activated carbon for heavy metal removal depends on metal type, water chemistry, pH, activated carbon pore structure, surface functional groups, and operating conditions.[1][2][3][4]
To support your projects as a professional activated carbon manufacturer and exporter, this article explains how activated carbon removes heavy metals, which metals are easier to capture, where activated carbon works best, and when specialized adsorbents or combined processes are required.[5][6][1]
Heavy metals are metallic elements with relatively high density that can be toxic or bioaccumulative even at low concentrations, such as lead (Pb), cadmium (Cd), chromium (Cr), copper (Cu), zinc (Zn), mercury (Hg), nickel (Ni), and arsenic (As). Many industrial and mining activities discharge heavy metals into water bodies, where they can accumulate in sediments, enter the food chain, damage ecosystems, and threaten human health.[1][5]
Regulatory agencies around the world set strict limits for heavy metals in drinking water, industrial effluents, and groundwater, making reliable heavy‑metal removal technologies—including activated carbon—essential for compliance.[6][5][1]
Activated carbon removes heavy metals mainly by adsorption and surface reactions, where metal ions bind to functional groups, pores, and active sites on the activated carbon surface. The dominant mechanisms include physical adsorption, electrostatic attraction, ion exchange, and surface complexation with oxygen‑ and nitrogen‑containing groups on activated carbon.[7][3][8][4][1]
In many studies, the adsorption kinetics of heavy metals on activated carbon follow pseudo‑second‑order models, indicating that chemisorption and surface reactions significantly influence removal performance. These mechanisms can be strengthened by modifying activated carbon with acids, bases, nitrogen, sulfur, or metal oxides to create more active sites for heavy metal binding.[8][4][9][10][11][7]
Different forms of activated carbon behave differently in heavy‑metal removal applications because of variations in particle size, pore structure, and contact time.[3][1]
- Powdered activated carbon (PAC) offers very fine particles and large external surface area, which is ideal for rapid adsorption in batch or contact‑tank systems for water and wastewater treatment.[3][1]
- Granular activated carbon (GAC) is used in fixed‑bed filters and biological activated carbon (BAC) filters, combining adsorption with biological processes; spent GAC can sometimes show enhanced metal ion removal through ion exchange mechanisms.[10][3]
- Pelletized or extruded activated carbon is commonly used in gas‑phase systems to remove mercury and other heavy metals from flue gases when impregnated with specific chemicals.[2][6]
By adjusting raw materials (coal, coconut shell, wood, biomass), activation method, and impregnation, manufacturers can design activated carbon grades optimized for specific heavy metals and process conditions.[11][6][1]
Activated carbon can remove a broad range of metal ions from water, but removal capacity varies significantly among different metals.[1][3]
Studies on activated carbon show that adsorption capacities often follow an order such as Cu(II) > Cr(VI) > Pb(II) > Zn(II) > Cd(II) under specific conditions, indicating that copper and chromium may be more strongly adsorbed than zinc or cadmium on a given activated carbon. Another study using tire‑derived activated carbon achieved monolayer adsorption capacities up to 322.5 mg/g for Pb(II), 185.2 mg/g for Cu(II), and 71.9 mg/g for Zn(II), which were much higher than a reference commercial activated carbon in the same test.[12][7][3]
Activated carbon—especially when modified—has been applied successfully to remove heavy metals such as Pb, Cd, Cu, Zn, Ni, Cr, and Hg from aqueous solutions, as well as mercury and other metals from industrial gas streams. Performance depends strongly on pH, competing ions, and the specific chemical form of each metal (for example, Cr(III) vs Cr(VI)).[9][2][6][3][1]
Several complementary mechanisms explain why activated carbon can capture heavy metals effectively in many systems.[4][11][1]
- Electrostatic attraction occurs between charged activated carbon surfaces and oppositely charged metal ions, strongly influenced by solution pH, point of zero charge (PZC) of the activated carbon, and ionic strength.[7][8][10]
- Ion exchange involves replacement of protons or other cations on activated carbon surface functional groups (such as carboxyls) by metal ions, and can dominate in some systems using commercial or spent activated carbon.[13][10][7]
- Surface complexation forms inner‑sphere complexes between metal ions and oxygen‑, nitrogen‑, or sulfur containing groups on activated carbon, enhancing selectivity and stability of adsorption.[4][9][1]
Chemical modification such as nitric‑acid oxidation or nitrogenation can increase the number of surface carboxyl and nitrogen groups, significantly improving adsorption rate and capacity for ions such as Cu(II). In some cases, impregnating activated carbon with metal sulfides or other reactive species yields strong and selective adsorption of mercury and related metals.[14][2][6][9][4]
The performance of activated carbon for heavy metal removal is sensitive to several operational and material parameters.[11][3][1]
- Solution pH controls metal speciation, surface charge of activated carbon, and competition with hydrogen or hydroxide ions, making pH optimization one of the most important design steps.[9][3][1]
- Coexisting ions and natural organic matter (NOM) can either enhance or reduce adsorption; for example, low levels of NOM may promote adsorption for some metals, while higher concentrations or certain species can compete for sites and reduce removal efficiency.[5][3]
- Activated carbon dosage provides more surface area and active sites at higher doses, increasing removal percentage but sometimes lowering adsorption capacity per gram if many sites remain unused.[2][3]
Temperature, initial metal concentration, contact time, and activated carbon pore size distribution also influence removal performance, and adsorption is often rapid in the first few minutes before slowing as equilibrium is approached. Correctly selecting and dosing activated carbon, and controlling process conditions, is essential to achieve target heavy‑metal limits.[8][6][3][11][1]
Recent research has focused on biomass‑derived and waste‑based activated carbon as cost‑effective, sustainable heavy‑metal adsorbents. Biomass‑derived activated carbon from agricultural and forestry residues can be engineered with high surface area and functional groups suitable for metal adsorption, reducing both waste and environmental impact.[15][6][9][1]
Waste‑based carbon adsorbents, including nano‑activated carbons from mine coal and tire‑derived activated carbon, have shown high adsorption capacities for metals like Pb, Cu, and Zn, sometimes outperforming conventional commercial activated carbon. Modifying these carbons with acids, oxidative treatments, or nitrogen‑containing groups further enhances their heavy‑metal adsorption performance and reusability.[14][7][4][9][11]
Activated carbon is widely used to remove mercury and other volatile metals from flue gases and industrial off‑gases, especially when chemically impregnated. In gas‑phase applications, impregnated activated carbon combines physical adsorption with chemical reactions, precipitating metals such as mercury in the pores of the activated carbon and binding them in stable forms.[6][2]
For gas streams with low metal concentrations, high‑iodine value coconut shell activated carbon or columnar activated carbon is often recommended to provide strong adsorption capacity and mechanical strength. Correct temperature control is crucial, because higher temperatures may enhance diffusion but can also damage functional groups and reduce adsorption capacity if too high.[2][6]
Although activated carbon is a versatile adsorbent, it is not always the best sole solution for every heavy‑metal problem. Some heavy metals or oxidation states do not bind strongly to unmodified activated carbon under certain pH conditions, and competing ions, high salinity, or complexing agents can significantly reduce adsorption efficiency.[3][5][6][9][1]
In high‑concentration wastewaters or where metals must be recovered, alternative or complementary methods such as precipitation, ion exchange resins, membrane filtration, or specialized sorbents may be more suitable. In many advanced systems, activated carbon is combined with coagulation, biological treatment, or resins to deliver robust, cost‑effective heavy‑metal removal and polishing.[15][5][6]
In real water and wastewater projects, activated carbon is often used as part of the treatment train rather than a stand‑alone step. Potential roles for activated carbon in heavy‑metal removal include polishing after chemical precipitation, simultaneous removal of organic contaminants and some metals, and emergency or seasonal dosing of powdered activated carbon in response to sudden contamination events.[5][6][15][1][3]
Biological activated carbon (BAC) filters using granular activated carbon can also play a role in heavy‑metal control, especially when spent activated carbon accumulates surface groups that enable ion‑exchange removal of metals such as Pb and Cd at low concentrations. Spent activated carbon with enhanced surface carboxyl content can exhibit maximum removal rates above 95% for Pb(II) and more than 86% for Cd(II) at very low concentrations, significantly higher than fresh activated carbon in the same system.[10]
Activated carbon can indeed remove heavy metals from water and gases, particularly when the activated carbon is properly selected, modified, and applied under optimized pH and operating conditions. For metals such as lead, copper, zinc, nickel, chromium, and cadmium, both conventional and advanced waste‑based activated carbon grades have demonstrated strong adsorption and ion‑exchange capacities in laboratory and full‑scale systems.[7][10][14][1][3][6]
At the same time, activated carbon has limitations: not all heavy metals or speciation states are equally adsorbed, and high‑load or complex wastewaters may require combined treatment methods. By tailoring activated carbon properties, using impregnation and surface modification, and integrating activated carbon into well‑designed treatment trains, industrial users can achieve reliable, cost‑effective heavy‑metal control while also removing organic pollutants and improving overall water and air quality.[9][11][1][4][6][5]
Activated carbon—especially acid‑modified or nitrogen‑doped grades—can show high adsorption capacities for Pb(II), with some waste‑based activated carbons achieving monolayer capacities above 300 mg/g under optimized conditions. In full‑scale biological activated carbon systems, spent granular activated carbon has achieved more than 95% removal of Pb(II) at low concentrations, significantly outperforming virgin activated carbon through ion‑exchange mechanisms.[13][10][14][7]
Activated carbon can remove chromium, but performance strongly depends on whether chromium is present as Cr(III) or Cr(VI), as well as pH and surface functional groups on the activated carbon. In some studies, adsorption capacity for Cr(VI) is lower than for Cu(II) or Pb(II), and organic matter or competing ions can reduce removal efficiency, so chromium control often combines activated carbon with reduction–precipitation or other treatment steps.[3][6][9][5]
Surface modification of activated carbon with acids, oxidizing agents, nitrogen, sulfur, or metal oxides generally increases the number and strength of binding sites for heavy metals, improving both adsorption capacity and selectivity. For example, nitric‑acid oxidation and nitrogenation have been reported to significantly enhance Cu(II) adsorption by increasing oxygen‑ and nitrogen‑containing surface functional groups on activated carbon.[11][14][4][9]
Spent activated carbon from biological activated carbon filters can continue to remove heavy metals effectively because accumulated biofilm and surface oxidation create abundant carboxyl and other functional groups that support ion exchange. In one full‑scale example, spent activated carbon used for five years showed much higher removal rates for Pb(II) and Cd(II) than virgin activated carbon at low metal concentrations, demonstrating a valuable reuse pathway.[10]
In some low‑to‑moderate concentration applications, well‑designed activated carbon systems can meet regulatory limits on heavy metals; however, in many industrial wastewater cases, activated carbon is used as a polishing step after primary removal processes. Combining precipitation, coagulation, filtration, ion exchange, or membranes with activated carbon adsorption offers more robust control, especially under variable loads or where ultra‑low residual metal concentrations are required.[15][1][6][5]
